DX360LCA-7M

DX360LCA-7M

  • dx360lca-7m-develon-20231024074758.jpg

DX360LCA-7M

Model : DX360LCA-7M
Operating Weight : 37,600kg
Bucket Capacity  : 1.81m3
Engine
Model  : DEVELON DX12
 Rated Power
: Gross-238kW(319HP)@1,800rpm
Net   - 233kW(312HP)@1.800rpm

Emission: Tier II
Type :
Water cooled, 4 Cycle ,Waste gate Controlled Turbocharger, Mechanical Direct Injection
Numbers of Cylinders : 6
Bore & Storke  : 123 mm x 155 mm
Maximum Torque : 1,400 Nm @ 1,200 rpm
Piston Displacement  : 11,051 cc
Main Pump : Parallel Bent Axis, Axial Piston Pump
Max Flow  : 2x350 l/min
Swing Speed :  0 to 9.3 rpm
Travel Speed (Fast/ Slow)   :   5.5/3.4 km/hr (3.4/2.1mph)
Maximum Grade: 35(70%)
Track Shoe  : 600mm
Dimension & Working Range :
Boom Length
: 6,500mm
Arm Length : 3,200mm
Max.Digging Reach :11,120mm
Max.Digging Depth : 7,485mm
Max.Digging Height: 10,215mm
Max.Dumpping Height: 8,605mm
Overall Dimension (WxLxH): W 3,280 mm x L 11,315 mm x H 3,100 mm


  • Category : Heavy Excavators
  • Brand : DEVELON
  • Total View : 556
